Although they share the same base material, each grade differs significantly in UV transmission range, bubble/ inclusion content, thermal stability, and purity. Choosing the wrong grade can lead to reduced light efficiency, premature failure in high-temperature environments, or contamination risks in semiconductor processes.



This guide provides engineers, optical designers, and procurement teams with a full comparison of JGS1, JGS2, and JGS3, including spectral performance, key properties, industrial applications, and selection recommendations.













Grade Summary



- JGS1: Deep UV grade, ultra-high purity, optimized for applications requiring transmission below 220 nm.

- JGS2: Balanced UV transmission grade, ideal for most UV optical and laboratory applications.

- JGS3: General-purpose grade, prioritizes thermal stability over deep UV performance.





JGS1 (Deep UV Grade)



- Key Advantage: The only grade with high transmittance down to 185 nm, making it essential for deep UV lithography and vacuum UV applications.

- Limitation: Higher production cost due to strict purity and bubble control requirements.



JGS2 (UV Grade)



- Key Advantage: Excellent transmission from 220 nm through visible and near-IR, suitable for UV curing, fluorescence spectroscopy, and most common UV optics.

- Limitation: Poor performance below 220 nm.



JGS3 (General Grade)



- Key Advantage: Lowest cost, with good thermal shock resistance for high-temperature applications.

- Limitation: Significant absorption below 260 nm, not suitable for most UV optical systems.









When to Choose JGS1



- Deep UV lithography & semiconductor inspection

- Vacuum UV optical systems

- UV spectroscopy requiring <220 nm transmission

- High-precision optical windows for scientific instruments



When to Choose JGS2



- UV curing lamps and equipment

- UV sterilization systems

- Laboratory cuvettes and optical cells

- General UV optical components (lenses, windows, filters)



When to Choose JGS3



- High-temperature furnace tubes and components

- General industrial heating elements

- Non-UV optical applications requiring heat resistance

- Low-cost high-temperature glass parts









Mistake 1: Using JGS3 for UV Curing



- Problem: Poor UV transmittance leads to low curing efficiency.

- Solution: Upgrade to JGS2 for all UV curing applications.



Mistake 2: Using JGS1 for High-Temperature Furnace Tubes



- Problem: Unnecessary high cost with no performance benefit.

- Solution: JGS3 is fully sufficient for high-temperature industrial applications.



Mistake 3: Choosing JGS2 for Deep UV Lithography



- Problem: Inadequate deep UV transmission causes system failure.

- Solution: JGS1 is the only grade suitable for deep UV processes.









We offer precision custom quartz glass components in all three grades:



- JGS1 deep UV optical windows, lenses, and prisms

- JGS2 UV curing lamps, optical cells, and laboratory components

- JGS3 high-temperature furnace tubes, plates, and industrial parts

- Custom cutting, polishing, and coating services for all grades









Q: Which grade is best for UV applications?

A: JGS2 is the standard choice for most UV applications. Choose JGS1 only if you need transmission below 220 nm.



Q: Can JGS3 be used for optical applications?

A: JGS3 is not recommended for optical systems due to its poor UV transmittance and higher inclusion levels.



Q: What is the main difference between JGS1 and JGS2?

A: The primary difference is the deep UV cutoff. JGS1 transmits down to 185 nm, while JGS2 starts at 220 nm.
