Optical Materials

This material hub provides side-by-side comparison of optical substrates, with clear differentiation between crystal quartz, fused silica and synthetic fused silica, plus infrared material performance tables.

Technical Articles In This Category

Sapphire Optical Material Properties

Topic: UV-MWIR transmission, mechanical hardness, thermal stability, crystal orientation & birefringence

Overview

Sapphire (single-crystal α-Al₂O₃) is one of the most durable optical substrates, widely used for high-temperature windows, protective cover glass and harsh-environment EO/IR optics. It delivers broadband transmission from deep UV to mid-infrared, extreme scratch resistance and outstanding thermal shock resistance. Felix Glass supplies C-axis and A-axis oriented sapphire blanks, polished windows and custom machined components with AR coatings for UV, visible and MWIR wavebands.

Core Optical Performance

  • Transmission Range: 150 nm ~ 5.5 μm; high transmittance >80% across 0.4–2.5 μm without coating.
  • Refractive Index: n≈1.76 at 589 nm; uniaxial crystal with birefringence (ordinary & extraordinary rays).
  • Birefringence Note: Birefringence disappears when light propagates parallel to the C-axis; always specify crystal orientation for polarized optical systems.

Mechanical & Thermal Properties

  1. Hardness: Mohs 9 (second only to diamond), Vickers hardness ~2200 kg/mm²; excellent scratch & abrasion resistance.
  2. Thermal Performance: Melting point 2045°C; high thermal conductivity (30–33 W/m·K); low thermal expansion, survives rapid thermal cycling without cracking.
  3. Chemical Resistance: Resists strong acids, alkalis and plasma etching; ideal for vacuum and semiconductor process viewports.

Typical Application Boundaries

1. Best for: high-temperature observation windows, rugged display cover glass, IR protective domes, plasma viewports. 2. Limitation: Brittle under heavy impact; not suitable for ultra-long wave infrared beyond 5.5 μm. 3. Coating match: Broadband AR coatings greatly improve surface transmission for imaging and laser systems.

Crystal Quartz vs Fused Silica vs Synthetic Fused Silica

Topic: UV transmission cutoff, impurity content, OH absorption, thermal expansion & laser damage threshold

Overview

Many engineers confuse three common SiO₂-based optical materials: natural crystal quartz, conventional fused silica and high-purity synthetic fused silica. The key differences lie in UV transmission purity, water (OH) absorption and thermal stability, which directly determine suitability for deep-UV lasers, spectroscopy and high-power laser optics.

1. Material Structure & Purity Difference

  • Crystal Quartz (Natural Single Crystal): Crystalline structure, high Fe/Ti impurities; strong UV absorption below 220 nm; low cost, only for visible & near-UV applications.
  • Standard Fused Silica (Natural Melted Quartz): Amorphous glass, moderate impurities; transmission cutoff ~220 nm; affordable for general UV-Vis optics.
  • Synthetic Fused Silica (High-Purity CVD SiO₂): ppb-level metal impurities; deep-UV transparent down to 185 nm; low OH grade eliminates the 2.7 μm IR water absorption band; top choice for excimer lasers (193 nm ArF) and deep-UV spectroscopy.

2. Key Optical & Thermal Comparison

  1. UV Cutoff: Crystal quartz ≈220 nm; regular fused silica ≈220 nm; synthetic fused silica down to 185 nm.
  2. OH Absorption Band: High-OH grades have strong absorption near 2.7 μm; low-OH synthetic fused silica removes this peak for near-infrared transmission.
  3. Thermal Expansion: All three have ultra-low CTE; fused silica has far better thermal shock resistance than crystalline quartz; can withstand quenching from 1000°C into cold water.
  4. Laser Damage Threshold: Synthetic fused silica delivers the highest LIDT for UV pulsed lasers, free from impurity-induced absorption hotspots.

Quick Material Selection Rules

• Deep-UV (193/248 nm excimer laser): Choose low-OH synthetic fused silica (JGS1 grade). • General UV-Vis (≥260 nm): Standard fused silica is cost-effective. • Near-infrared (2–3.5 μm): Select low-OH fused silica to avoid the 2.7 μm water absorption peak. • Polarized optical paths: Only use single-crystal quartz and control crystal axis orientation to manage birefringence.

ZnSe & ZnS Infrared Substrate Selection

Topic: Transmission spectrum, hardness, thermal conductivity, CO₂ laser absorption & multi-spectral imaging performance

Overview

CVD-grown ZnSe and ZnS are the two dominant mid-infrared substrate materials for CO₂ laser optics and thermal imaging windows. The choice hinges on laser absorption, mechanical hardness, multi-band transmission and cost. ZnSe is the gold standard for 10.6 μm CO₂ laser systems; ZnS offers higher hardness and better environmental durability for rugged IR imaging domes.

1. Optical Transmission Performance

  • ZnSe: Transmission range 0.6–16 μm; ultra-low absorption coefficient at 10.6 μm (0.0005 cm⁻¹), the ideal substrate for high-power CO₂ laser windows and lenses.
  • Standard CVD ZnS: 0.7–14 μm; slightly higher IR absorption than ZnSe; not recommended for high-power continuous-wave CO₂ lasers.
  • Multi-Spectral ZnS (Clear ZnS): Improved purity, extends transmission into visible band; works for combined visible + MWIR multi-band optical systems.

2. Mechanical & Thermal Trade-offs

  1. Hardness: ZnS (Knoop 200–235) is nearly twice as hard as ZnSe (Knoop 120); ZnS windows resist scratching better in field-deployed equipment.
  2. Thermal Conductivity: Multi-spectral ZnS (27.2 W/m·K) outperforms ZnSe (18 W/m·K); better heat dissipation reduces thermal lensing under laser power load.
  3. Temperature Limit: Both materials degrade above 250°C in air; avoid prolonged high-temperature exposure without protective coatings.

3. Final Selection Guide

• High-power 10.6 μm CO₂ laser cavities & output windows: Pick CVD ZnSe with low-absorption AR coating. • Rugged thermal imaging domes, outdoor IR cameras: Choose standard CVD ZnS for higher mechanical strength. • Multi-band systems (visible + 3–5 μm MWIR): Select multi-spectral clear ZnS for broad-spectrum transmission. • Cost note: ZnSe and standard ZnS have similar raw material costs; the main price difference comes from polishing and coating specifications.
