Medical Grade Glass for Medical Displays & Touch Screens | CT MRI X-Ray Cover Glass | Felix Glass
- Price
- US $7.55-9.66
- Model
- FG-MED-GRADE-001
- MOQ
- 5 piece
Item specifics
- Material
- Medical Grade High‑Strength Tempered Glass
- Thickness
- customizable, OEM/ODM supported
- Surface
- Anti‑Bacterial, Anti‑Fingerprint, Anti‑Glare, Wear‑Resistant
- Application
- Medical Imaging, CT/MRI/X‑Ray, Medical Monitor, Touch Screen, Medical
- Shape
- Flat / 2.5D / Narrow Bezel
Review
Description
Medical Grade Glass for Medical Displays & Touch Screens | Medical Equipment Cover Glass Manufacturer
Custom Medical Grade Tempered Glass Manufacturer
Felix Glass produces medical grade glass for hospital monitors, diagnostic touch panels and imaging equipment. Full covered keywords: Medical Grade Glass, medical touch panel glass, medical screen protector glass, medical equipment glass cover, medical monitor cover glass. Full in-house precision machining, medical-grade polishing, chemical tempering, biocompatible silk printing and AG/AR/AF coating, single prototype and medical device mass OEM production supported.
✅ ISO 9001 Certified
✅ 19+ Years Precision Display Glass Manufacturing
✅ Biocompatible, Easy-To-Disinfect Surface Treatment
✅ Custom Size, Printing & Medical Optical Coatings
✅ MOQ 1 Prototype
✅ Fast Global Medical Device OEM Delivery
Technical Specifications
Parameter Capability
Base Material High-purity aluminosilicate medical grade glass
Thickness Range 0.7mm – 4.0mm customizable
Tempering Performance DOL 40–90μm, CS 650–900MPa, 9H anti-scratch
Surface Treatment Disinfectant-resistant AF coating, AG anti-glare, AR anti-reflection
Edge Options C/J fine chamfer, smooth rounded edge, no sharp burrs
Printing Standard Medical-grade non-toxic ink, ±0.03mm light-shield border printing
Inspection Standard 100% AOI full defect inspection, cleanroom production
Material Selection Guide
Medical Grade Aluminosilicate Glass
Best For: CT/MRI/X-ray monitors, diagnostic touch panels, bedside medical equipment
Advantages: Biocompatible, resistant to alcohol & medical disinfectants, high transmittance, long-term anti-stain performance, stable coating adhesion
Manufacturing Capability
Closed-loop full in-house cleanroom production flow:
Raw Glass Cutting → CNC Precision Machining → Smooth Edge Polishing → Non-toxic Silk Printing → Chemical Tempering → Medical-Grade AG/AR/AF Coating → AOI Inspection → Dust-Free Protective Film Lamination
Strict hygiene & optical control to meet medical device long-cycle disinfection and clear imaging requirements.
Application Solutions (Problem & Solution)
Medical Imaging Monitor (CT/MRI/X-Ray)
Problem: Screen reflection and glare distort lesion imaging judgment
Solution: AR coated medical monitor cover glass, low reflectance for accurate medical image observation
Hospital Diagnostic Touch Panel
Problem: Fingerprint residue and disinfectant stains obscure touch operation
Solution: Medical touch panel glass with durable AF anti-fouling coating, easy wipe and sanitize
Bedside Patient Monitoring Equipment
Problem: Surface scratches and harsh chemical erosion shorten equipment service life
Solution: Hardened medical screen protector glass with deep tempering and corrosion-resistant surface
Project Cases
Hospital Radiology Monitor Project
Custom AR coated medical monitor cover glass with C chamfer, mass supplied to global medical imaging equipment brands.
Portable Diagnostic Touch Device Project
Medical grade touch panel glass with disinfectant-resistant AF coating, stable hygiene performance for clinical daily use.
Quality Control & Testing Equipment
100% full cleanroom inspection before shipment with professional test instruments:
AOI Visual Detector: Detect micro scratch, printing pinhole and coating uneven defects
Glass Stress Tester: Verify tempering DOL and anti-scratch hardness
Chemical Resistance Tester: Validate surface stability under repeated medical disinfectant wiping
Haze & Reflectance Tester: Test AR coating anti-glare optical performance
Third-party biocompatibility & medical standard test reports available for medical OEM projects.
Why Choose Felix Glass
19+ years professional medical grade display glass manufacturing experience
Full cleanroom production line for medical device glass processing
Specialized disinfectant-resistant medical AF/AR/AG coating technology
Strict biocompatible ink and substrate material selection for clinical scenarios
Flexible prototype sampling & stable bulk supply for global medical equipment OEM clients
ISO9001 certified factory direct pricing without middlemen
FAQ
What is medical grade glass?
It is biocompatible tempered glass with anti-disinfectant surface treatment, designed for hospital monitors, touch panels and diagnostic imaging equipment, resistant to alcohol and medical sanitizers.
What’s the application of medical monitor cover glass?
It is used as front protective panel for CT, MRI, X-ray and patient bedside monitors, reducing reflection to ensure clear medical imaging viewing.
Can medical touch panel glass withstand repeated disinfection?
Yes, our medical AF coating resists daily alcohol and disinfectant wiping without coating peeling or staining.
Are all medical glass processed in cleanroom?
Yes, all cutting, polishing, coating and inspection procedures are finished in dust-free cleanroom to avoid particle contamination for medical equipment.
Can I get prototype samples for medical device certification?
Yes, MOQ 1 piece for medical touch screen and monitor glass testing & qualification.
Related Products
Industrial HMI C/J Tempered Cover Glass Safe chamfer touch glass for factory automation control terminals
Laptop AR AF Touch Screen Glass Ultra-thin anti-glare protective glass for office notebook displays
Automotive Infotainment Touch Cover Glass AR/AF coated tempered glass for vehicle cockpit screens
Streaming Rearview Mirror Glass AR AG coated tempered mirror cover for car ADAS & DVR
AG AR AF Functional Coated Glass Multi-functional optical coating display protective panels
Request a Custom Quote
Send your medical glass drawing, thickness, printing pattern and AG/AR/AF coating requirements.
Our medical optical engineering team will provide customized medical grade glass solutions and factory quotation within 24 hours.
Video Description
| FELIX GLASS GROUP | |||
| >> HONG KONG FELIX OPTICAL GLASS CO., LIMITED | |||
| Global International Marketing Department, Hong Kong, China | |||
>> DONGGUAN FELIX GLASS MFG CO.,LTD | |||
Manufacturing Base, Dongguan, China | |||
>> HUIZHOU FELIX GLASS MFG CO.,LTD | |||
Manufacturing Base, Huizhou, China | |||
>> SUZHOU FELIX GLASS MFG CO.,LTD | |||
Manufacturing Base, Suzhou, China | |||
>> VIETNAM FELIX GLASS MFG CO.,LTD | |||
Manufacturing Base, Vietnam |
| Custom Display Cover Glass Manufacturer | |||
| AR, AF & AG Coated Optical Glass for Industrial, Medical, Automotive & Outdoor Displays |
Improve Visibility. Enhance Durability. Protect Your Display.
Poor visibility under sunlight, fingerprint contamination, surface scratches, and impact damage are common challenges for modern touch display systems.
Felix Glass develops high-performance display cover glass engineered to improve optical clarity, user experience, and long-term durability across demanding industrial and commercial applications.
Our custom display glass combines precision optical processing, advanced surface coatings, and strengthened glass technology to deliver reliable performance in harsh operating environments.
Whether you are designing a medical monitor, industrial HMI, EV dashboard, self-service kiosk, or outdoor touchscreen device, we provide fully customized cover glass solutions tailored to your project requirements.
| application scenarios | |||
| FELIX GLASS1. Medical Display Cover Glass SolutionsUsed in medical monitors, surgical touch panels, diagnostic devices, and beauty equipment. Supports alcohol resistance and anti-bacterial AF coating.
⸻
2. Industrial HMI & Automation GlassUsed in CNC machines, industrial control panels, handheld terminals, and outdoor automation systems. AG coating improves readability under strong light.
⸻
3. Automotive & EV Display GlassUsed in car central control screens, dashboards, rear-seat displays, and LiDAR optical windows. Resistant to temperature change and vibration.
⸻
4. Self-Service Kiosk Glass PanelsUsed in kiosks, ticket machines, checkout systems, and hotel check-in terminals. High durability for frequent public touch.
⸻
5. Outdoor & Public Terminal GlassUsed in charging piles, outdoor kiosks, security panels, and smart lockers. Designed for harsh weather environments.
⸻
6. Custom Optical Glass SolutionsUsed in smart home systems, marine control panels, surveying instruments, and precision devices with custom optical requirements.
|
| Why Choose Felix Glass? | |||
| FELIX GLASS |
| FELIX GLASS is a precision glass manufacturer with 19+ years of experience in optical glass, optical lenses, and AR / AG / AF coated cover glass.We provide custom manufacturing and high-volume production for industrial, medical, automotive, and electronic applications, supporting projects from prototype development to mass production.
Our production system is used by 1,000+ industrial customers worldwide for stable and repeatable manufacturing results.
| |||
| Manufacturing Capabilities | • ISO 9001 certified production system, compliant with RoHS and CE requirements | ||
• 19+ years of experience in precision glass processing and optical coating technologies | |||
• Full-cycle support from prototype to mass production (1,000+ completed projects) | |||
• Controlled supply chain with secured raw material inventory | |||
• In-house CNC machining, coating, printing, and inspection processes | |||
• Stable global delivery performance with controlled production scheduling | |||
• 100% final inspection before shipment, inspection reports available on request | |||
| • Engineering support for structure, material, and process optimization | |||
• Rapid prototyping for custom engineering validation | |||
• Flexible MOQ from 100–1000 pcs depending on product complexity | |||
Small quantity (100-1000pcs) available | |||
| COMPANY EXHIBITION | |||
| FELIX GLASS |
| 📂 Send Your Design Files Upload drawings, sketches, or samples for fast quotation and engineering review. We support both concept and production-stage projects. ⸻ ✔ Supported Formats PDF / DXF / DWG / STEP / IGES / AI / EPS / CDR Please convert text to outlines or include font files if needed. ⸻ ✔ Recommended Files STEP / DXF / DWG files are preferred for highest accuracy and stable production. ⸻ ⚠️ Notes JPG / PNG files are accepted for reference only and may require clarification. ⸻ 📦 Physical Samples Accepted for reverse engineering, matching, or replacement projects. ⸻ 🔒 NDA Protection All files are strictly confidential. NDA available on request. ⸻ 🧠 Engineering Check We review design feasibility, materials, and coating compatibility before production. | ||
| | ||
| >>Glass Material Selection Guide Choose the right glass based on optical, strength, and application requirements. If unsure, send us your application for engineering recommendation. ⸻ 📏 Thickness 0.25 – 8.0 mm (custom available) ⸻ 🌈 Transparency • Clear Glass – Cost-effective • Low Iron Glass – High clarity (>93%) • Smoked Glass – Privacy / hidden display ⸻ 💪 Strength • Soda Lime – Standard use • Aluminosilicate – Higher impact resistance • High Alumina – Industrial grade ⸻ ⚙️ Applications • Industrial → Strengthened glass • Medical → Low iron glass • Outdoor → AR + AG glass • Optical → BK7 / optical glass • High temp → Borosilicate ⸻ 📩 Not sure? Send your drawing or application. We will recommend the best material within 24 hours. | ||
| | ||
| >>Manufacturing Capabilities Precision processing for custom cover glass. ⸻ 🧩 Methods • CNC cutting – high precision shapes • Laser cutting – fine holes and details • Waterjet cutting – thick glass, stress-free Methods can be combined for best results. ⸻ 🧱 Structures Shapes, holes, chamfers, countersinks, blind holes, 2.5D edges. ⸻ ✨ Finishing Grinding / polishing / ultrasonic cleaning ⸻ 📩 Need Help? Send your drawing. We will recommend the best process. | ||
| | ||
| >>Ultimate VersionTempering Process
Improves glass strength and safety performance.
⸻
Chemical Tempering
Below 2.0 mm
Ion-exchange in potassium nitrate bath.
⸻
Thermal Tempering
Above 2.0 mm
High-temperature heating and rapid quenching.
| ||
| | ||
| >>Printing Capabilities We provide custom printing of patterns, logos, and colors on cover glass. ⸻ 🧩 Printing Methods • Screen Printing – precise, durable solid colors • Digital Printing – gradients, full-color designs ⸻ 🎨 Color Matching Pantone / RAL / physical samples available for accurate color matching. ⸻ 🧪 Ink Options • Standard ink • High-temperature resistant ink • UV-resistant ink • Light-diffusing ink • Semi-transparent ink • Infrared (IR) transparent ink | ||
| | ||
| >>Anti-Fingerprint (AF) Coating AF coating creates a fingerprint-resistant surface and improves surface cleanliness and smooth touch performance. ⸻ ✨ Performance • Water contact angle ≥115° • Anti-smudge and oil resistance • Easy cleaning surface • Smooth touch experience ⸻ ⚙️ Function Reduces fingerprints, oil residue, and stains on glass surfaces while maintaining optical clarity. | ||
| | ||
| >>Anti-Reflective (AR) Coating AR coating reduces surface reflection and increases light transmission for improved optical clarity. ⸻ ✨ Performance • Single-side AR: up to ~95% transmittance • Double-side AR: up to ~98% transmittance • Reduces surface reflection (<1%) • Enhances image sharpness and contrast ⸻ ⚙️ Applications Suitable for: • High-definition display systems • Cameras and imaging devices • Optical sensors • Industrial and medical displays | ||
| | ||
| >>Anti-Glare (AG) Treatment AG treatment reduces surface reflections and improves visual comfort by minimizing glare and eye fatigue. ⸻ ✨ Performance • Reduces glare and reflected light • Improves readability in bright environments • Enhances user comfort during long-term use ⸻ 📊 Gloss Level Options • Gloss > 80 — Indoor applications (high clarity) • Gloss 50–70 — Semi-outdoor / mixed lighting environments • Gloss 20–30 — Touch panels (paper-like visual feel) ⸻ ⚙️ Applications Widely used in: • Medical equipment • E-readers and electronic paper displays • Automotive display systems • Financial payment terminals • Outdoor display devices | ||
| | ||
| >> Mirror Electroplating Metal coatings deposited on glass to form reflective or functional surfaces. ⸻ ⚙️ Materials Al / Cr – reflective mirror layer ITO – transparent conductive layer (touch enabled) Ni – metallic finish (non-touch) ⸻ ✨ Applications Smart mirrors / switch panels / HMI / decorative glass | ||
| | ||
| >>Infrared (IR) Transmitting Glass IR glass blocks visible light while transmitting infrared for sensing and recognition systems. ⸻ 📊 Performance • Visible light: < 2% • IR transmission: > 90% @ 820 / 940 nm ⸻ ⚙️ Applications Face recognition / Iris recognition / IR sensors / Remote control windows / Security systems ⸻ 🎨 Options IR coating / IR printing / Black or red filter glass | ||
| CUSTOMER AND FEEDBACK | |||
| FELIX GLASS |
| BERNAT BONNIN CEO Medical Devices.S.A | ||
Our Company Working with FELIX GLASS was an absolute pleasure! The product quality exceeded my expectations, and the customer service team was incredibly responsive. From order to delivery,everything was seamless. l'm already planning my next purchase-highly recommend to anyone looking for Display glass panel and optical lens! |
>>Display Cover Glass FAQ – Engineering, Manufacturing & Procurement Guide：
🟢 PART 1 —TRAFFIC FAQ
1. What Is Display Cover Glass?
Display cover glass is the protective outer layer used on LCD, OLED, TFT, and touch displays. It protects against scratches, impact, dust, and chemicals while maintaining optical clarity and touch performance.
⸻
2. What Is Cover Glass Used For?
It is widely used in industrial, medical, automotive, and commercial display systems.
⸻
3. What Is AR AG AF Glass?
AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) coatings improve visibility, reduce reflection, and enhance touch experience.
⸻
4. What Is Dead Front Glass?
Dead front glass appears black when the display is off and becomes transparent when backlit.
⸻
5. What Glass Is Used for Touch Screens?
Common materials include aluminosilicate glass, soda lime glass, and chemically strengthened glass.
⸻
6. What Is the Best Glass for Outdoor Displays?
AR + AG coated chemically strengthened glass is most suitable for outdoor environments.
⸻
🟡 PART 2 — ENGINEERING & MATERIAL FAQ
7. What Is the Difference Between AR, AG, and AF?
AR reduces reflection, AG reduces glare, AF prevents fingerprints.
⸻
8. Can AR, AG, and AF Be Combined?
Yes. This is called 3A glass and is widely used in industrial and medical displays.
⸻
9. What Is the Difference Between AR Glass and AG Glass?
AR improves clarity; AG improves readability in bright environments.
⸻
10. Does AG Reduce Glass Strength?
Proper AG glass with chemical strengthening maintains high mechanical strength.
⸻
11. What Is the Hardness of Cover Glass?
Chemically strengthened glass can reach up to 9H hardness.
⸻
12. What Is Haze in Glass?
Haze refers to light scattering; higher haze improves anti-glare but reduces sharpness.
⸻
13. What Thickness Should I Choose?
• <7”: 0.55–1.1mm
• 7–15”: 1.1–2.0mm
• 15–32”: 2.0–4.0mm
• 32”+: 4.0–6.0mm
⸻
14. Can Glass Be Curved or 2.5D?
Yes, flat, 2.5D, curved, and irregular shapes are available.
⸻
15. Can Glass Be Drilled or Cut After Strengthening?
No. All machining must be done before tempering or chemical strengthening.
⸻
16. What Is Optical Bonding?
Optical bonding uses optically clear adhesive to bond glass and display, improving visibility and durability.
⸻
17. What Is the Difference Between Single and Double AG?
Single AG has one treated surface; double AG reduces glare more but slightly reduces clarity.
⸻
18. What Materials Do You Offer?
Soda lime, aluminosilicate, borosilicate, and Gorilla Glass.
⸻
19. Can You Customize Glass?
Yes, including shape, size, coating, printing, holes, and slots.
⸻
20. Do You Provide Engineering Support?
Yes, we support material selection, structure optimization, and manufacturability review.
⸻
🟠 PART 3 — PROCUREMENT & ORDER FAQ
21. How Do I Get a Quote?
Send drawings, dimensions, material, coating, quantity, and application details.
⸻
22. How Fast Can I Get a Quote?
Usually within 2–24 hours.
⸻
23. What Is Your MOQ?
Typically 100–1000 pcs depending on complexity.
⸻
24. Can I Get Samples?
Yes, standard samples can be free; custom samples may have cost.
⸻
25. What Is Sample Lead Time?
3–7 working days for most custom projects.
⸻
26. What Is Mass Production Lead Time?
10–15 working days depending on complexity.
⸻
27. Can You Handle Urgent Orders?
Yes, expedited production is available.
⸻
28. What Payment Methods Do You Accept?
T/T, PayPal, L/C and others.
⸻
29. Can You Work From Drawings?
Yes, CAD/STEP/2D drawings are accepted.
⸻
30. Do You Offer NDA Protection?
Yes, we can sign NDA for all custom projects.
⸻
31. Can You Support Full Production Cycle?
Yes, from prototype to mass production and long-term supply.
⸻
32. Can You Help Reduce Cost?
Yes, through material and process optimization.
⸻
🔵 PART 4 — QUALITY & TESTING FAQ
33. How Do You Ensure Product Quality?
Through IPQC, final inspection, and full process control.
⸻
34. Do You Provide Inspection Reports?
Yes, upon request.
⸻
35. What Tests Are Performed on Glass?
Transmission, haze, reflection, thickness, hardness tests.
⸻
36. What Tests Are Done on Coatings?
Contact angle, abrasion resistance, adhesion tests.
⸻
37. What Standards Do You Follow?
ISO9001, RoHS, REACH compliant production.
⸻
🔴 PART 5 — LOGISTICS & GLOBAL DELIVERY FAQ
38. Do You Ship Internationally?
Yes, we ship to Europe, North America, Asia, and Middle East.
⸻
39. What Shipping Methods Are Available?
DHL, FedEx, UPS, and sea freight.
⸻
40. How Is Glass Packed?
Multi-layer protective packaging with foam, film, and shock-resistant crates to prevent breakage.
⸻
🟢 PART 6 — Why Choose Felix Glass?
Felix Glass is a professional manufacturer specializing in high-precision display cover glass solutions for industrial, medical, automotive, and commercial applications.
With over 19 years of experience in optical glass processing, we provide stable OEM/ODM manufacturing and engineering support from prototype development to mass production.
Our Advantages:
• Full in-house processing capability (cutting, grinding, coating, printing)
• AR / AG / AF coating expertise
• Fast engineering response within 24 hours
• Stable quality control system (IPQC & final inspection)
• Support for custom drawings and complex designs
• Global shipping to Europe, North America, and Asia
We don’t just manufacture glass — we help customers turn designs into reliable, production-ready products.
