High Precision Fused Silica Optical Mirror | Protected Al / Au Coating for Laser & IR Systems
- Model
- FG-FS-MIRROR-ALAU
Item specifics
- Material:
- UV Fused Silica Quartz Glass
- Structure
- : Plano Flat Mirror / Spherical Concave Focusing Mirror
- Coating Option
- : Protected Aluminum Coating, Protected Gold Coating
- Function
- : Beam Steering, Light Focusing, Optical Path Folding, IR / UV Reflection
- Customization
- Size, Radius, Thickness, Edge Treatment, Coating Spectrum
Review
Description
Custom Fused Silica High-Reflection Flat & Concave Optical Mirrors (Aluminum / Gold Coating)
Felix Glass manufactures custom precision reflective Fused Silica Optical Mirror based on high-purity UV fused silica substrate. Available in two mainstream structures: plano flat mirrors for beam steering and spherical concave mirrors for light focusing. Metallic aluminum coating and infrared gold coating are optional to match UV, visible and infrared optical requirements.
Fused silica quartz glass features ultra-low thermal expansion coefficient, excellent thermal stability and superior broadband transmittance. Compared with ordinary optical glass, it maintains stable surface flatness and reflective performance under high-power laser irradiation and long-term continuous industrial operation.
Core Coating Performance
1. Protected Aluminum Coating
Provides high broadband reflectivity across UV, visible and near-infrared spectrum (200 nm – 2 μm). Widely adopted for general beam folding, laboratory optical platforms, machine vision and laser transmission systems. The protective dielectric layer prevents oxidation and improves mechanical durability.
2. Protected Gold Coating
Delivers extremely high reflectivity in mid-to-far infrared range (1.5 μm – 10 μm). Ideal for infrared thermal imaging, FTIR spectroscopy, infrared detection and CO₂ laser optical systems. Gold coating minimizes infrared light absorption and ensures low-loss optical transmission.
Product Structure Features
Flat Plano Mirror
Maintains precise planar surface accuracy, mainly used for optical path folding, beam direction adjustment and optical system assembly without changing beam convergence state.
Spherical Concave Mirror
Features inward curved spherical surface, achieving effective light collection and beam focusing. Corrects light path without introducing chromatic aberration, suitable for focusing optics and infrared signal gathering systems.
Key Technical Advantages
1. Superior Thermal Stability
Fused silica substrate resists thermal deformation under high temperature and high-energy laser conditions, ensuring long-term stable reflective accuracy.
2. Customizable Optical Parameters
Support custom diameter, thickness, curvature radius, surface flatness, edge blackening and spectral coating specifications according to customer technical drawings.
3. Low Loss & High Uniformity
Precision surface polishing ensures uniform reflective performance, reducing scattered light and improving overall optical system stability.
4. Durable Metallic Coating
Coating with protective layer enhances scratch resistance and anti-oxidation performance, adapting to harsh industrial optical environments.
Typical Application Scenarios
- Laser beam delivery and high-power laser optical systems
- Infrared thermal imaging, infrared detection and spectroscopic instruments
- UV optical testing equipment and laboratory optical platforms
- Optical path folding and beam steering assemblies
- Industrial machine vision and precision optical measuring devices
- Medical infrared diagnostic and analytical optical equipment
OEM Manufacturing Capability
All processes including fused silica blank shaping, precision surface grinding, ultra-fine polishing, metallic coating deposition, protective film plating and final optical inspection are completed under standardized quality control.
We support prototype sampling, small-batch trial production and mass customization. Each mirror is strictly inspected for surface quality, flatness and reflective uniformity to meet industrial-grade optical integration standards.
FAQ
1. What are fused silica mirrors used for?
Fused silica optical mirrors are core reflective components for beam steering, optical path folding and light focusing. Widely used in laser systems, UV-IR optical instruments, spectroscopy and industrial precision optics.
2. Difference between aluminum coating and gold coating?
Aluminum coating offers broadband reflectivity for UV-visible-NIR range for general industrial optics. Gold coating provides ultra-high reflectivity specifically for mid and far infrared applications.
3. Why choose fused silica instead of BK7 glass?
Fused silica features lower thermal expansion and higher thermal stability, performing better under high-power laser and high-temperature working conditions with stable optical accuracy.
4. Can you customize size and curvature?
Yes. Custom diameter, thickness, concave radius, surface flatness and edge treatment are fully supported per customer optical design requirements.
5. Do you provide coated protective layer?
All metallic coatings come with protective dielectric coating to resist oxidation, abrasion and environmental erosion for prolonged service life.
Send us your type, dimensions, material requirements, optical specifications, coating requirements, and application details.
Our engineering team will review your project and provide a customized optical solution with manufacturing recommendations and quotation support
Video Description
