Model
FG-WIN-001

Item specifics

Material
Chemically strengthened aluminosilicate tempered glass
Mohs Hardness
Grade 7 scratch resistance
Custom Coating
Wavelength-matched AR anti-reflection + AF anti-fingerprint dual coating
Operating Temperature
-40℃ ~ 85℃ automotive wide temperature range
Thickness Options
1.2mm / 1.5mm / 2.0mm
Dimensional Tolerance
±0.01mm
Custom Processing
Irregular CNC cutting, mounting positioning holes, edge chamfer, shading silk screen
Application Scenarios
L2-L4 autonomous driving LiDAR modules,NEV ADAS system,Tier1 automotive optical assemblies,automotiv

Review

Description

Felix Glass Co., Limited · Model FG-WIN-001

1. ADAS LiDAR Laser Radar Optical Window Introduction

Felix Glass manufactures custom optical window glass for LiDAR modules, autonomous-driving ADAS assemblies, new-energy vehicles, and optical ranging or measurement equipment.

The source product specifies chemically strengthened aluminosilicate glass, wavelength-matched AR anti-reflective coating, optional AF anti-fingerprint coating, CNC profiles, mounting holes, chamfered edges, and black shading print.

This product remains in the Automotive Dashboard Display Glass category.

This optical window is a component, not a complete LiDAR or ADAS safety system. Final spectral transmission, optical distortion, environmental resistance, sealing, functional safety, and vehicle qualification must be validated at module and system level.

Felix Glass LiDAR optical window for ADAS module reference
Custom optical window for automotive LiDAR and ranging-sensor assemblies.
Wavelength-specific optics

2. AR Coating for LiDAR Laser Signal Transmission

The source describes an AR coating matched to the LiDAR laser wavelength to reduce surface reflection and optical loss. No wavelength, incidence angle, spectral curve, or transmission value is stated in the current description.

Spectral target

Define the operating wavelength or wavelength band, minimum transmission, maximum reflection, bandwidth, polarization condition, and incidence-angle range.

Ranging interface

Evaluate ghost reflection, wavefront error, wedge, flatness, coating color, and signal-to-noise effects on the actual transmitter and receiver geometry.

Environmental state

Measure optical performance before and after temperature, humidity, abrasion, contamination, cleaning, UV, and chemical exposures defined by the program.

Browse related automotive and optical components in the Felix Glass product catalog.

Chemically strengthened LiDAR window glass reference
Substrate strength depends on glass condition, edges, openings, thickness, and test method.
Protective substrate

3. Scratch-Resistant Strengthened Glass Performance

The visible attribute identifies chemically strengthened aluminosilicate glass and a Mohs hardness reference of grade 7. The source associates this substrate with resistance to sand, dust, gravel contact, and outdoor use.

  • Hardness: confirm the Mohs test method, reference minerals, sample surface, coating state, and acceptance criteria.
  • Impact and gravel: define projectile size, velocity, angle, temperature, support fixture, and pass conditions.
  • Edge strength: verify chamfer, microcrack limits, mounting loads, opening distance, and assembly stress.
  • Coating interaction: substrate hardness does not establish AR or AF abrasion life; coating wear requires a separate test.

Company and manufacturing information is available on About Us.

Environmental validation

4. Automotive Temperature and Thermal-Shock Resistance

The source lists an operating-temperature range of -40°C to 85°C and states that optical performance and coating integrity are maintained through automotive thermal cycling.

That claim requires a project-specific standard, ramp rate, dwell time, cycle count, humidity condition, powered or unpowered state, mounting condition, sample count, and post-test optical limits. The range alone does not establish vehicle qualification.

-40°C source limitConfirm cold dwell, thermal contraction, mounting stress, and optical readings.
85°C source limitConfirm hot dwell, coating behavior, print adhesion, and assembly compatibility.
Transition testingDefine thermal shock or cycle profile, number of cycles, recovery time, and failure criteria.
Drawing-based processing

5. Custom CNC Shapes and Mounting-Hole Processing

The source lists irregular CNC cutting, positioning holes, edge chamfers, and black shading silk-screen printing for LiDAR module structures and optical-instrument housings.

Thickness options1.2, 1.5, and 2.0 mm
Dimensional tolerance±0.01 mm source attribute; feature, datum, process capability, and inspection method must be specified
ProfilesCustom and irregular CNC geometry subject to drawing review
Mounting featuresPositioning holes with controlled edge distance, diameter, and datum scheme
EdgesChamfer and finish requirements matched to handling and assembly
Shading printBlack silk-screen zones, optical apertures, fiducials, and cosmetic limits defined by artwork

A single ±0.01 mm statement should not be assumed to apply to every dimension. Identify critical dimensions, profile tolerance, hole position, flatness, thickness, and measurement equipment separately.

Custom CNC LiDAR optical window glass reference
Custom geometry should be released through controlled CAD, datums, and inspection criteria.
Surface contamination control

6. AF Coating for Dust, Mud, Water, and Fingerprint Residue

The source describes an AF surface intended to reduce adhesion of fingerprints, dust, mud, and water stains that could affect the LiDAR optical path.

AF performance should be defined by initial and post-wear contact angle, sliding angle, oil marker behavior, cleanability, abrasion cycles, chemical exposure, and optical change. AF coating does not by itself provide module ingress protection or a dustproof seal.

Read related coating and maintenance guidance in the Felix Glass blog.

LiDAR optical window inspection and clean handling reference
Inspection should connect each optical or cosmetic requirement to a documented method.
Production inspection

7. Cleanroom Handling and CCD Optical Inspection

The original description states that production uses a “Class 100” dust-controlled workshop and CCD automatic optical inspection. It also states that batches are checked for transmittance, flatness, friction resistance, and temperature shock before delivery.

For supplier qualification, request the cleanroom classification standard, certified zone, monitoring interval, particle records, CCD resolution, defect library, lighting geometry, sampling plan, traceability, calibration, and inspection-report format.

CCD appearanceParticles, scratches, chips, coating defects, print defects, and aperture contamination.
Optical checksSpectral transmission, reflectance, flatness, wedge, distortion, and coating uniformity.
RecordsLot ID, sample size, method, equipment, results, limits, disposition, and report approval.
Specification checklist

8. LiDAR Optical Window Test Items and Source Data

The table consolidates the source attributes and converts the narrative claims into items that can be placed in a drawing, control plan, or validation protocol.

MaterialChemically strengthened aluminosilicate glass
Hardness referenceMohs grade 7; method and coating condition require confirmation
CoatingWavelength-matched AR plus AF dual-coating option
Operating-temperature reference-40°C to 85°C
Thickness1.2, 1.5, or 2.0 mm
Dimensional reference±0.01 mm source attribute, subject to feature-specific capability review
Optical testsSpectral transmission, reflectance, flatness, wedge, wavefront or image distortion, and coating uniformity as applicable
Surface testsHardness, abrasion, contact angle, cleanability, chemical exposure, and cosmetic inspection
Environmental testsTemperature cycling or shock, humidity, UV, contamination, cleaning, vibration, and gravel or impact as required
System applications

9. Compatible ADAS and Optical Measurement Equipment

The source identifies L2–L4 autonomous-driving LiDAR modules, new-energy-vehicle ADAS systems, Tier 1 automotive optical assemblies, and optical measurement instruments.

Vehicle LiDARProtective transmit-and-receive windows for roof, fascia, grille, or integrated sensor modules.
ADAS assembliesCustom windows for sensor stacks used in driver-assistance and automated-driving development.
Tier 1 modulesDrawing-controlled optical components requiring production traceability and program documentation.
Measurement equipmentOptical ranging and surveying instruments operating in outdoor or contamination-prone conditions.

Use Contact Us to request project-specific coating data and validation documentation.

ADAS LiDAR and optical measurement window application reference
Compatibility requires review of wavelength, field of view, mounting, cleaning, and environment.
Program support

10. OEM Prototype and Production Service

The source states that prototype sampling and volume OEM production are available for autonomous-driving solution providers, vehicle manufacturers, Tier 1 suppliers, and optical-equipment manufacturers.

  1. 1Receive CAD, optical aperture, wavelength, and environment requirements
  2. 2Review material, strengthening, AR/AF stack, printing, and tooling
  3. 3Confirm drawing, test methods, documentation, and sample plan
  4. 4Build prototypes and evaluate optical and environmental results
  5. 5Freeze approved design, process route, and control plan
  6. 6Release production and monitor lot traceability and change control

Start from the Felix Glass home page for a broader view of glass processing and coating capabilities.

Program context

11. Market Context for LiDAR Optical Components

The original outline describes LiDAR optical measurement components as a developing market area. This page does not make a market-size, growth-rate, vehicle-adoption, or supplier-share claim.

For sourcing decisions, evaluate the actual program nomination, forecast, design life, validation plan, capacity, tooling ownership, change-control process, quality agreement, delivery location, service requirements, and end-of-life obligations.

Drawing review checklist

12. Submit a LiDAR Module Drawing for Quotation

Send the CAD drawing, optical aperture, LiDAR wavelength and bandwidth, angle of incidence, minimum spectral transmission, maximum reflection, flatness, wedge, thickness, datums, tolerance map, mounting holes, edge finish, print artwork, AR/AF requirements, cleaning method, environmental tests, sample quantity, annual volume, documentation needs, and requested schedule.

Send LiDAR requirements
